30021
Go EFI Classic Black 650HP System
$1,144.00
FiTech Part Number: 30021
In stock
This product falls under the following Emissions Category:
WARNING: Hazardous Material Warning Close WARNING: This product can expose you to chemicals including Nickel Acetate, Chromium, Lead, Lead Compounds, Nickel (Metallic), Nickel Compounds, Diisonyl Phthalate (DINP) and Toluene which are known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Description
FiTech Fuel Injection’s Go EFI Classic Black revolutionary fuel injection system allows you to maintain the classic carburetor look while eliminating cold start issues, hesitation, vapor lock, and flooding. This innovative classic design hides the injectors and has an externally mounted ECU so it can be mounted wherever you want to ensure a true carburetor look is maintained. The Go EFI Classic Black is a self-tuning fuel injection system rated for up to 650hp. The more you drive the more it adapts to your personal style. So it is perfect for your everyday driver, your weekend Street Machine, or your Bracket Racer.
Features
- Matte black finish.
- The included Genuine Bosch LSU 4.2 Wideband Oxygen Sensor provides real time Fuel Map Learning!
- Dual Pattern bolt on carburetor replacement, designed to fit 4150 Flange & Spread Bore manifolds.
- Included clamp-on oxygen sensor kit ensures a leak free oxygen sensor installation, with stainless steel T-Bolt clamps and a stainless steel (Weldable) oxygen sensor flange.
- Externally mounted ECU to maintain that classic carburetor look.
- High-flow aluminum throttle body with four 45mm diameter throttle bores to increase the air flow for additional horsepower gains and large CM engines.
- (4) Injectors support up to 650hp.
- All sensors excluding the O2 and coolant sensor are integrated directly into the throttle body.
- Works with original carb-type distributor, factory-style throttle linkage, and most four barrel intake manifolds.
- High resolution full color touchscreen for setup, tuning, and gauge displays.
Kit Contents
- (1) Die-cast throttle body.
- (1) Remote ECU
- (1) O2 bung kit.
- (1) Hand-held controller.
- (1) CTS sensor.
- (1) Hand-held controller cable.
- (1) CTS adapter.
- (1) Windshield mount.
- (1) Mini USB cable.
- (1) O2 sensor.
- (1) Gasket kit.
Not Included:
This system needs a fuel delivery system to provide 58 PSI of fuel pressure. A Fuel pump, fuel lines, fuel filter, and fuel pressure regulator are needed for this kit. Below is a list of fuel system components that may be needed.
Part # | Item |
50004 | Go Fuel Force Fuel Surge Tank |
50005 | Go Fuel Dual Pump Force Fuel Surge Tank |
50006 | Go Fuel Force Fuel Mini Surge Tank |
50015 | Go Fuel in Tank Fuel Pump 800 HP Module |
50019 | Go Fuel in Tank Fuel Pump Returnless Module With 2 Inch Fill |
54001 | Go Fuel Tight Fit Regulator with Pressure Gauge |
54002 | Go Fuel Regulator with Pressure Gauge |
51003 | Go Fuel AN-6 Stainless Steel 40 Ft Hose Kit with Filter |
51004 | Go Fuel AN-6 Black Stainless Steel 40 Ft Hose Kit with Filter |
View All Master Kits
_________________________________________________________________________
For FiTech Fuel Injection Tech Videos:
Check in for tips and tricks from the FiTech experts!
Additional information
Weight | 14 lbs |
---|---|
Dimensions | 12.5 × 15 × 9.5 in |
Additional information
Weight | 13 lbs |
---|---|
Dimensions | 16 × 11 × 14 in |
Maximum Horsepower: | 650 HP |
Injection Style: | Throttle body |
Timing Control Compatible: | No |
Power Adder Compatible: | No |
ECU Included: | Yes |
Fuel Pump Included: | No |
Transmission Controller Included: | No |
Metering Style: | Speed density (Map-N) |
Intake Manifold Included: | No |
Intake Section Included: | No |
Engine Block Deck Height: | No |
Throttle Body Mounting Flange: | 4-barrel square bore |
Venturi Quantity: | 4 |
Venturi Diameter (mm): | 44 mm |
Airflow Rate (cfm): | 900 cfm |
Throttle Body Material: | Aluminum |
Throttle Body Finish: | Satin black |
Injectors Included: | Yes |
Injector Size (lbs/hr): | 80 lb. |
Calibration Module Included : | Yes |
Wiring Harness Included: | Yes |
Oxygen Sensor Included: | Yes |
MAP Sensor Included: | Yes |
IAT Sensor Included: | Yes |
TPS Sensor Included: | Yes |
Quantity: | Sold individually. |
Universal: | Yes |
Fuel Type: | Alcohol, Gasoline, MethaNol, Flex |
